Peterometer Chapter 1: Tracking Hydration

March 8, 2019

This is the first in a series of posts I hope to write about building tools for “Peterometer”, a way to visualize stats I’ve collected about myself.

Inspiration for Peterometer

I’ve long been inspired by people who build beautiful visualizations of their gathered metrics. For example, Nicholas Felton’s annual reports. Here is an example from his 2007 report:

The first page of Nicholas Felton's 2007 annual report
The first page of Nicholas Felton’s 2007 annual report

I think this format of visualization is really cool. It’s easy to glance at while being information-dense.

Another cool example is Anand Sharma’s April Zero, which is now an app called Gyroscope:

An image of Gyroscope
An image of Gyroscope

He has some great posts about his creative process here and here. The Iron Man-style HUD influence shines through in the finished product.

These visualizations are really cool ways to show stats gathered about your life. I’ve recently been getting more into tracking my day-to-day life, and experimenting with visualization techniques to showcase this data.

Hydration Tracking

Since December 2018, I’ve been tracking my hydration every day. Every time I finish drinking something, I log the type of drink it was, and how much of it I drank. I log the data using the WaterMinder app on my watch and phone. WaterMinder lets you have saved drinks, which is really helpful if you drink the same thing often (my Nalgene, a cup of coffee from the machine at work, etc.)

Some Visualizations

WaterMinder lets you export your data in CSV format. With a little bit of Python, we can parse this into a “stream” stacked area chart to show how I hydrate myself:

A stacked area plot of my hydration

This chart is a bit tough to read due to data density. The legend is sorted in descending order of consumption. By the numbers, this is:

Drink fluid oz.
Water 4159.7
Coffee 1482.7
Soda 826.9
Sports Drink 761.9
Tea 751.4
Smoothie 398.0
Carbonated Water 381.4
Energy Drink 273.6
Beer 225.0
Protein Shake 162.0
Liquor 130.0
Juice 94.0
Coconut Water 81.6
Milk 55.1
Wine 17.6
Hot Chocolate 15.0
Total 9815.9

Using the chart and table there are some interesting takeaways:

Analyzing My Dog's DNA

January 21, 2019

Dogs are awesome. Since March of 2014, I’ve owned a little dog named Riker:

Riker the small dog outside
Riker the small dog outside

I adopted her from the Humane Society in Milpitas. She was 8 weeks old. She recently had her fifth birthday. Happy birthday Riker! I love her very much.

Anyways, when I got her, I was curious about what type of dog she was. She looks like a chihuahua, but has some features that don’t match the traditional chihuahua:

I thought she might have been part Shiba Inu. These dogs are adorable and have the curled tail and gradient-banded coat. Here’s one from Wikipedia:

A shiba inu dog outside on grass
A shiba inu dog outside on grass

Doesn’t this dog look like Riker? With the tail and banded coat? I thought so too.

Whenever other people asked me about Riker, I would tell them she’s “part chihuahua, part shiba inu”. They believed me, but I didn’t have any proof.

Enter Embark

A good friend of mine told me about a service where you can get your dog’s DNA analyzed. It’s called EmbarkVet (disclaimer: this is a referral link). Embark gives your dog a breed report, health analysis, and some cool genetic information. It’s like 23andMe for your dog.

I signed up for the service. A few days later they sent me a DNA swab kit. It’s like an oversized q-tip. After sticking this in Riker’s cheeks for 30 seconds or so (she wasn’t happy about this, but I told her it was for science), I packed the kit in the return shipping and sent it off.

Over the next few weeks, Embark notified me as the analysis progressed. After 3 weeks or so, my pressing question was answered: they told me what type of dog she was!

Less than 50% chihuahua

To my absolute amazement, Riker is not even mostly chihuahua! The results confirm that Riker is a pomeranian! The full breakdown is:

I also learned that she has 1.5% “Wolfiness”, which indicates ancient wolf genes that have survived through to modern domesticated dogs. Cool!

Note: I am not a trained biologist. Regrettably, I spent much of my college biology course playing Pokémon Crystal, although I do remember some parts of the genetics sections.

A family tree

Embark also determines haplotypes, which means they can tell what genes of Riker’s came from which parents. This lets them generate a family tree:

Riker's family tree
Riker’s family tree

This means Riker’s parents were a chihuahua mix and a purebred pomeranian.

Analyzing my dog’s DNA

Besides finally being able to see my dog’s genetic history, I was super happy that I could download the raw genetic data. When I unzipped the file, I was left with two text files:

riker.tfam // 75B
riker.tped // 6.7MB

(I renamed them for brevity)

I searched for information on these file types. They both seem to be related to the free PLINK genetics software package.

If we download PLINK and run it on these files, we get:

$ plink --tfile riker
Processing .tped file... 77%
Error: Invalid chromosome code '27' on line 166046 of .tped file.
(This is disallowed for humans.  Check if the problem is with your data, or if
you forgot to define a different chromosome set with e.g. --chr-set.)

This is pretty cool! PLINK defaults to human DNA. This file is from a dog, not a person. Looking through the plink --help file, we can see that they have support for lots of species:

--cow/--dog/--horse/--mouse/--rice/--sheep : Shortcuts for those species.

(I wonder why rice is so interesting to the software…)

Anyways, let’s run it with the --dog flag:

$ plink --dog --tfile riker
Processing .tped file... done.
plink.bed + plink.bim + plink.fam written.

PLINK wrote these files to the same directory:

$ ls
plink.bed
plink.bim
plink.fam
plink.log
riker.tfam
riker.tped

These look to be PLINK metadata files that the software uses to do its processing.

We can use PLINK to do some interesting sounding genetic computations. For example, if we run it with the --homozyg flag, we can see homozygosity reports. According to Wikipedia (I must have been in Johto during this part of biology), zygosity is “the degree of similarity of the alleles for a trait in an organism”. Running it produces:

$ plink --dog --tfile riker --homozyg
1 dog (0 males, 1 female) loaded from .fam.
--homozyg: Scan complete, found 27 ROH.
Results saved to plink.hom + plink.hom.indiv + plink.hom.summary .

The software knows that the dog is female, which is pretty cool. The files it generated seem to indicate the degree of homozygosity for her individual genes. Neat!

If we run with the --het flag, we can see inbreeding coefficients. The file it produces show this:

O(HOM)    E(HOM) N(NM)  F
     0 3.051e+04 61022 -1

From this helpful documentation I found online:

O(HOM)    Observed number of homozygotes
E(HOM)    Expected number of homozygotes
N(NM)     Number of non-missing genotypes
F         F inbreeding coefficient estimate

-1 looks like it indicates a sampling error or contamination according to the docs:

The estimate of F can sometimes be negative. Often this will just reflect random sampling error, but a result that is strongly negative (i.e. an individual has fewer homozygotes than one would expect by chance at the genome-wide level) can reflect other factors, e.g. sample contamination events perhaps.

We can also use the software to find what parts of the genotyping are missing with the --missing flag. From this, I was able to gather that Riker only has a missing SNP rate of 0.0009034 (less than 1%). I think this means that Riker’s DNA in this sample is over 99% complete. Cool!

I may make Riker’s DNA available online some day for others to do genetic analysis.

Anyways, I thought this was a fun exercise into how genetic data is stored and processed. It’s really cool that there is open source software to analyze this data. Thanks for reading!

Live Markdown previews from vim

January 6, 2019

This is more of a technical post

This site is written using Markdown, which:

allows you to write using an easy-to-read, easy-to-write plain text format, then convert it to structurally valid XHTML (or HTML)

It’s a common technique for writing blogs, as it lets the author write text in the text editor of their choice.

I write this page in vim, which is a command line text editor. I love vim for many reasons that are outside the scope of this post. I’ve been using it as my primary editor for almost 5 years. I wanted a good solution for writing Markdown in vim.

Because vim is a command line editor, it makes it tougher to use it to write rich text. In a GUI program, rich text can be rendered inline and as-you-edit. A command line tool can show you the formatting you have applied to text, but it does not give you an accurate rendering of how your content will look as you edit it.

I wanted to continue to use vim to edit my blog posts (I find vim plugins for other editors to be a worse approximation than “I can’t believe it’s not butter”). This post is about how I solved this problem.

A Markdown preview app

On macOS, you can get apps to render Markdown in a window. One that I like a lot is Marked, which automatically refreshes its preview when the Markdown file changes. This means you can open a .md file in Marked and get live updates as you change it. This can be used with any editor, including vim. The flow is something like:

As you save to it with :w, the preview will be auto-refreshed. I like this, but wanted to open it with a single key combination.

Adding Marked to vim

We can write a vim function to help us with this. Something like this:

function OpenInMarked2()
    " Open the file in Marked here
endfunction
Running a shell command from vim

We can use ! to run a command from our function. Technically, this is the filter command. From :help !:

!{motion}{filter} Filter {motion} text lines through the external program {filter}.

You can try this in your vim. Just run :!pwd, and you should be presented with your shell and your current working directory. Below it, vim helpfully tells us “Press ENTER or type command to continue”.

This is great! Using this and the macOS open command, we can at least launch Marked 2 with something like this:

!open -a Marked\ 2.app

But what about opening the current file? vim lets us use % from Ex commands as a stand-in for the path to the current file. So we can do something like:

!echo %

to see the current file. We can use this with open to open the current file in vim:

!open -a Marked\ 2.app %

This is the body of our OpenInMarked2 function:

function OpenInMarked2()
    !open -a Marked\ 2.app %
endfunction

Once we have this function, we can call it with the Ex call command, like this:

:call OpenInMarked2()

This will open the current file in Marked, but will leave us at the shell with “Press ENTER or type command to continue” there. We still have to press enter before we can edit the file live.

Defining a mapping

We can use a vim mapping to call the function for us. A mapping lets us take a key combination and map it to a command. For the key combination, I like to use <leader>, which is a user-controlled modifier in vim. This means that <leader> _ is wide open for use in your .vimrc. For my leader key, I use , (comma), as it’s near the other modifiers on a US keyboard. For leader mappings, I like a mnemonic key combination, as it makes it easier to remember.

A good choice for this mapping, which is applicable for Markdown and for opening Marked, is <leader>m. Our mapping to call the function might look like this:

nmap <silent> <leader>m :call OpenInMarked2()

Here’s a decoder ring for what these commands mean:

If you add this mapping and function to your .vimrc, you’ll see that it works kind of. You have to hit enter to get the command to actually run, and then after doing so you’re left at the shell, so you need to hit enter again before returning to the editor.

Hitting enter twice

We can add a press of the enter key to our mapping using <CR>. This acts as though the user has pressed the carriage return. We’ll add two of them, as we need one to run the function and another to return to the editor. Our mapping now looks like this:

nmap <silent> <leader>m :call OpenInMarked2() <CR> <CR>

which is the mapping you’ll find in my .vimrc.

I hope you found this post helpful. I have been using OpenInMarked2 to help me write Markdown for 2 years now, and I think it’s a cool example of how to extend vim to fit your needs.

New Site, Who Dis?

December 31, 2018

This is the first post on my new website! You’re reading this on the brand new peterhajas.com. Let’s break it down.

A (not so new) domain

It’s worth noting that this page is also hosted on peter.haj.as. I have had this domain from American Samoa for some time. I love the idea of domains that are people’s names with no added alphanumeric characters, and this one fits the bill for me.

My own static site generator - what could possibly go wrong?

My old page was powered by Hyde. While this project provides a lot of flexibility, I felt that I was not using all of its features. I wanted something dead-simple that could enable me to write more. As a result, I wrote my own.

This site is still statically-generated from Markdown, but it’s now done with a Bash script with only one dependency (a markdown binary). This makes it easier to set up on a new machine. It also lets me really understand how the site works.

The site generates quickly, and it’s been a great learning opportunity! For example, I learned how to format dates using date (see here). I’m still learning (I don’t know web layout very well, for example) but I think it’s better to jump in with both feet when learning something new.

The site is missing some stuff (like RSS support), but I plan to iterate on it over time.

Hopefully I’ll write more

All of this is for naught if I don’t actually use the damn thing to write and think out loud.

I hadn’t updated my old webpage in over 6 years. There’s so much that has happened in that time that I want to write about, like:

Fingers crossed I’ll write about these things in the (near) future on this page.
